Specifications
GPU Engine Specs:
CUDA Cores
16384
Boost Clock (MHz)
2580
Base Clock(MHz)
2235
Thermal and Power Spec:
Minimum System Power Requirement (W)
850
Supplementary Power Connectors
3x PCIe 8-pin cables (adapter in box) OR 450 W or greater PCIe Gen 5 cable
Memory Specs:
Memory Clock
21Gbps
Standard Memory Config
24GB
Memory Interface
GDDR6X
Memory Interface Width
384-bit
Memory Bandwidth (GB/sec)
1008
Feature Support:
Real-Time Ray Tracing
Yes
Ray Tracing Cores
3rd Generation
Tensor Cores
4rd Generation
NVIDIA Architecture
Ada Lovelace
Microsoft DirectX
12 Ultimate
NVIDIA DLSS
3
PCI Express Gen 4
Yes
NVIDIA GeForce Experience
Yes
NVIDIA Ansel
Yes
NVIDIA FreeStyle
Yes
Bus Support
PCI-E 4.0 X16
NVIDIA ShadowPlay
Yes
NVIDIA Highlights
Yes
OS Certification
Windows 10, Linux, FreeBSDx86
NVIDIA G-SYNC-Ready
Yes
Lighting Module
Programmable RGB: Aura Sync, Mystic Light, Polychrome, RGB Fusion
Game Ready Drivers
Yes
NVIDIA Studio Drivers
Yes
NVIDIA GPU Boost
Yes
Vulkan API
Yes
OpenGL
4.6
HDMI 2.1
Yes
DisplayPort 1.4a
Yes
NVIDIA Encoder
2x 8th Generation
NVIDIA Decoder
5th Generation
Accessories:
Installation Guide
Yes
Power Guide
Yes
Graphics Card Dimensions:
Length 334mm
Height 148mm
Width 3-slot
Display Support:
Multi Monitor
Yes
Maxmium Digital Resolution
7680×4320
HDCP
2.3
Standard Display Connectors
HDMI 2.1,
3x DisplayPort 1.4a
