PLEASE NOTE THAT THESE CARDS ARE DESIGNED FOR GAMING PURPOSES AND MAY BE UNSUITABLE FOR MINING OR BLOCKCHAIN PURPOSES.
THESE CARDS COULD CONTAIN TECHNOLOGY TO RESTRICT PERFORMANCE IN CERTAIN SITUATIONS.
WARRANTIES FOR CARDS USED FOR THESE PURPOSES CAN BE INVALIDATED BY THE MANUFACTURER IN THE EVENT OF A FAILURE – PLEASE CHECK WITH THE MANUFACTURER DIRECTLY FOR FURTHER DETAILS.
GPU Engine Specs
CUDA Cores
3584
Boost Clock (MHz)
1777
Base Clock (MHz)
1320
Thermal and Power Spec
Minimum System Power Requirement (W)
550
Supplementary Power Connectors
8-pin
Memory Specs
Memory Clock
15Gbps
Standard Memory Config
12GB
Memory Interface
GDDR6
Memory Interface Width
192-bit
Memory Bandwidth (GB/sec)
360
Feature Support
Real-Time Ray Tracing
Yes
Ray Tracing Cores
2nd Generation
Tensor Cores
3rd Generation
NVIDIA Architecture
Ampere
Microsoft DirectX
12 Ultimate
NVIDIA DLSS
Yes
PCI Express Gen 4
Yes
NVIDIA GeForce Experience
Yes
NVIDIA Ansel
Yes
NVIDIA FreeStyle
Yes
Bus Support
PCI-E 4.0 X16
NVIDIA ShadowPlay
Yes
NVIDIA Highlights
Yes
OS Certification
Windows 10, Linux, FreeBSDx86
NVIDIA G-SYNC Ready
Yes
Lighting Module
None
Game Ready Drivers
Yes
NVIDIA Studio Drivers
Yes
NVIDIA GPU Boost
Yes
Vulkan API
Yes
OpenGL
4.6
HDMI 2.1
Yes
DisplayPort 1.4a
Yes
NVIDIA Encoder
7th Generation
NVIDIA Decoder
5th Generation
Accessories
Installation Guide
Yes
Power Guide
Yes
Graphics Card Dimensions
Length
240mm
Height
120mm
Width
2-slot
Display Support
Multi Monitor
Yes
Maximum Digital Resolution
7680 x 4320
HDCP
2.3
Standard Display Connectors
HDMI 2.1, 3x DisplayPort 1.4a
