PLEASE NOTE THAT THESE CARDS ARE DESIGNED FOR GAMING PURPOSES AND MAY BE UNSUITABLE FOR MINING OR BLOCKCHAIN PURPOSES.
THESE CARDS COULD CONTAIN TECHNOLOGY TO RESTRICT PERFORMANCE IN CERTAIN SITUATIONS.
WARRANTIES FOR CARDS USED FOR THESE PURPOSES CAN BE INVALIDATED BY THE MANUFACTURER IN THE EVENT OF A FAILURE – PLEASE CHECK WITH THE MANUFACTURER DIRECTLY FOR FURTHER DETAILS.
Specifications
GPU Engine Specs:
CUDA Cores
6144
Boost Clock (MHz)
1785
Base Clock(MHz)
1575
Thermal and Power Spec:
Minimum System Power Requirement (W)
750
Supplementary Power Connectors
8+8-pin
Memory Specs:
Memory Clock
19Gbps
Standard Memory Config
8GB
Memory Interface
GDDR6X
Memory Interface Width
256-bit
Memory Bandwidth (GB/sec)
608
Feature Support:
Real-Time Ray Tracing
Yes
Ray Tracing Cores
2nd Generation
Tensor Cores
3rd Generation
NVIDIA Architecture
Ampere
Microsoft DirectX
12 Ultimate
NVIDIA DLSS
Yes
PCI Express Gen 4
Yes
NVIDIA GeForce Experience
Yes
NVIDIA Ansel
Yes
NVIDIA FreeStyle
Yes
Bus Support
PCI-E 4.0 X16
NVIDIA ShadowPlay
Yes
NVIDIA Highlights
Yes
OS Certification
Windows 10, Linux, FreeBSDx86
NVIDIA G-SYNC-Ready
Yes
Game Ready Drivers
Yes
NVIDIA Studio Drivers
Yes
NVIDIA GPU Boost
Yes
Vulkan API
Yes
OpenGL
4.6
HDMI 2.1
Yes
DisplayPort 1.4a
Yes
NVIDIA Encoder
7th Generation
NVIDIA Decoder
5th Generation
Accessories:
Installation Guide
Yes
Power Guide
Yes
Graphics Card Dimensions:
Length 300mm
Height 112mm
Width 2-slot
Display Support:
Multi Monitor
Yes
Maxmium Digital Resolution
7680×4320
HDCP
2.3
Standard Display Connectors
HDMI 2.1, 3x DisplayPort 1.4aGPU Engine Specs:
CUDA Cores
6144
Boost Clock (MHz)
1785
Base Clock(MHz)
1575
Thermal and Power Spec:
Minimum System Power Requirement (W)
750
Supplementary Power Connectors
8+8-pin
Memory Specs:
Memory Clock
19Gbps
Standard Memory Config
8GB
Memory Interface
GDDR6X
Memory Interface Width
256-bit
Memory Bandwidth (GB/sec)
608
Feature Support:
Real-Time Ray Tracing
Yes
Ray Tracing Cores
2nd Generation
Tensor Cores
3rd Generation
NVIDIA Architecture
Ampere
Microsoft DirectX
12 Ultimate
NVIDIA DLSS
Yes
PCI Express Gen 4
Yes
NVIDIA GeForce Experience
Yes
NVIDIA Ansel
Yes
NVIDIA FreeStyle
Yes
Bus Support
PCI-E 4.0 X16
NVIDIA ShadowPlay
Yes
NVIDIA Highlights
Yes
OS Certification
Windows 10, Linux, FreeBSDx86
NVIDIA G-SYNC-Ready
Yes
Game Ready Drivers
Yes
NVIDIA Studio Drivers
Yes
NVIDIA GPU Boost
Yes
Vulkan API
Yes
OpenGL
4.6
HDMI 2.1
Yes
DisplayPort 1.4a
Yes
NVIDIA Encoder
7th Generation
NVIDIA Decoder
5th Generation
Accessories:
Installation Guide
Yes
Power Guide
Yes
Graphics Card Dimensions:
Length 300mm
Height 112mm
Width 2-slot
Display Support:
Multi Monitor
Yes
Maxmium Digital Resolution
7680×4320
HDCP
2.3
Standard Display Connectors
HDMI 2.1, 3x DisplayPort 1.4a
